AK4396VF-E2 IC Circuit Board Chips Electronics Components Chip IC Electronics

AK4396VF-E2 IC Circuit Board Chips Electronics Components Chip IC Electronics

Advanced Multi-Bit 192kHz 24-Bit ∆Σ DAC

FEATURES

• 128x Oversampling

• Sampling Rate: 30kHz ∼ 216kHz

• 24Bit 8x Digital Filter (Slow-roll-off option) Ripple: ±0.005dB, Attenuation: 75dB

• High Tolerance to Clock Jitter • Low Distortion Differential Output

• DSD data input available • Digital de-emphasis for 32, 44.1, 48kHz sampling

• Soft Mute • Digital Attenuator (Linear 256 steps)

• THD+N: −100dB • DR, S/N: 120dB

• I/F format : MSB justified, 16/20/24bit LSB justified, I2 S

• Master Clock: Normal Speed: 256fs, 384fs, 512fs, 768fs or 1152fs

Double Speed: 128fs, 192fs, 256fs or 384fs

Quad Speed: 128fs or 192fs DSD: 512fs or 768fs

• Power Supply: 5V ± 5% (Analog), 3.0 ∼ 5.25V (Digital)

• CMOS or TTL Level Digital I/F

• Package: 28pin VSOP

• Pin Compatible with AK4393/4/5

APPLICATIONS

● DATA ACQUISITION

● TEST AND MEASUREMENT

● INDUSTRIAL PROCESS CONTROL

● PERSONAL DIGITAL ASSISTANTS

● BATTERY-POWERED SYSTEMS

ABSOLUTE MAXIMUM RATINGS(1)

DESCRIPTION

The AK4396 is a high performance stereo DAC for the 192kHz sampling mode of DVD-Audio including a 24bit digital filter.

Using AKM's multi bit architecture for its modulator the AK4396 delivers a wide dynamic range while preserving linearity for improved THD+N performance.

The AK4396 has full differential SCF outputs, removing the need for AC coupling capacitors and increasing performance for systems with excessive clock jitter.

The AK4396 accepts 192kHz PCM data and 1-bit DSD data, ideal for a wide range of applications including DVD-Audio and SACD.

The AK4396 has a fully functional compatibility with the AK4393/4/5 and lower power dissipation.
