B3F -1000IC electronic pressure sensors 12A Current ± 5V Voltage

B3F-1000IC Pressure Sensor IC Electronics Components Chip IC Electronics

A Wide Range of Models: 6 x 6 mm, 12 x 12 mm, Vertical and High-force.

Excellent tactile feel combined with high life expectancy.

Available in stick packaging for automatic mounting to PCBs. Up to 2.55 N (260-gf) operating force for a firmer operating touch.

Pushbuttons available in nine colors.

ABSOLUTE MAXIMUM RATINGS(1)

DESCRIPTION

The AVS12 kit is an automatic mains selector (110/220V AC) to be used in SMPS < 500 W. It is composed of 2 devices :

• The Controller is optimized for low consumption and high security triggering of the triac. When connected to VSS, the mode input activates an additional option.

If the main power drops from 220V to 110V, the triac control remains locked to the 220V mode and avoids any high voltage spike when the voltage comes back to 220V. When connected to VDD, the mode input desactivates this option.

• The TRIAC is specially designed for this application. An optimization between sensitivity and dynamic parameters of the triac gate highly reduces the losses of supply resistor and allows excellent immunity against disturbances.
