MUR860G Rectifier Diode SWITCHMODE Power Rectifiers

: Large Image : MUR860G Rectifier Diode SWITCHMODE Power Rectifiers

Product Details:

Place of Origin:	original factory
Brand Name:	Anterwell
Certification:	new & original
Model Number:	MUR860G

Payment & Shipping Terms:

Minimum Order Quantity:	100pcs
Price:	Negotiate
Packaging Details:	Please contact me for details
Delivery Time:	1 day
Payment Terms:	T/T, Western Union, Paypal
Supply Ability:	45000pcs

Contact Now

Detailed Product Description

Peak Repetitive Reverse Voltage:	600 V	Working Peak Reverse Voltage:	600 V
DC Blocking Voltage:	600 V	Average Rectified Forward Current:	8.0 A
Operating Junction Temperature:	−65 To +175 °C	Storage Temperature:	−65 To +175 °C
Highlight:	diode rectifier circuit , bridge rectifier circuit

MUR805, MUR810, MUR815, MUR820, MUR840, MUR860

SWITCHMODE Power Rectifiers

ULTRAFAST RECTIFIERS 8.0 AMPERES 50−600 VOLTS

This series is designed for use in switching power supplies, inverters and as free wheeling diodes, these state−of−the−art devices have the following features:

Features

• Ultrafast 25, 50 and 75 Nanosecond Recovery Time

• 175°C Operating Junction Temperature

• Popular TO−220 Package

• Epoxy Meets UL 94 V−0 @ 0.125 in

• Low Forward Voltage

• Low Leakage Current

• High Temperature Glass Passivated Junction

• Reverse Voltage to 600 Volts

• Pb−Free Packages are Available*

Mechanical Characteristics

• Case: Epoxy, Molded

• Weight: 1.9 grams (approximately)

• Finish: All External Surfaces Corrosion Resistant and Terminal Leads are Readily Solderable

• Lead Temperature for Soldering Purposes: 260°C Max. for 10 Seconds

• Shipped 50 units per plastic tube

MAXIMUM RATINGS

Rating	Symbol	MUR						Unit
Rating	Symbol	805	810	815	820	840	860	Unit
Peak Repetitive Reverse Voltage Working Peak Reverse Voltage DC Blocking Voltage	V_RRM V_RWM V_R	50	100	150	200	400	600	V
Average Rectified Forward Current Total Device, (Rated V_R), T_C = 150°C	I_F(AV)	8.0						A
Peak Repetitive Forward Current (Rated V_R, Square Wave, 20 kHz), T_C = 150°C	I_FM	16						A
Nonrepetitive Peak Surge Current (Surge applied at rated load conditions halfwave, single phase, 60 Hz)	I_FSM	100						A
Operating Junction Temperature & Storage Temperature	T_J, Tstg	-65 to +175						°C

Maximum ratings are those values beyond which device damage can occur. Maximum ratings applied to the device are individual stress limit values (not normal operating conditions) and are not valid simultaneously. If these limits are exceeded, device functional operation is not implied, damage may occur and reliability may be affected.
