Product Details:
Payment & Shipping Terms:
|
| VBatt: | 28 V | Supply Current: | 1.5 A |
|---|---|---|---|
| Relay Control Output Current (DC): | 200 MA | Power Dissipation Tamb = 90°C: | 500 MW |
| Storage Temperature Range Tstg: | –55 To +125 °C | ||
| Highlight: | circuit board ic,electronic components ic |
||
Features
►Internal frequency-to-voltage converter
►Externally-controlled integrated amplifier
►Overload limitation with a “fold back” characteristic
►Optimized soft-start function
►Tacho monitoring for shorted and open loop
►Automatic retriggering switchable
►Triggering pulse typ. 155 mA
►Voltage and current synchronization
►internal supply-voltage monitoring
►Temperature reference source
►Current requirement ≤ 3 mA
Description
The integrated circuit U211B2/ B3 is designed as a phase control circuit in bipolar technology with an internal frequency-voltage converter. Furthermore, it has an internal control amplifier which means it can be used for speedregulated motor applications.
It has an integrated load limitation, tacho monitoring and soft-start functions, etc. to realize sophisticated motor control systems.
Figure 1. Block diagram (Pins in brackets refer to SO16) *) Pins 5 and 18 connected internally
