PVT322S Zener Diode IC Electronics Components Program ic Chip Memory IC

: Large Image : PVT322S Zener Diode IC Electronics Components Program ic Chip Memory IC

Product Details:

Place of Origin:	Malaysia
Brand Name:	IR
Certification:	Original Factory Pack
Model Number:	PVT322S

Payment & Shipping Terms:

Minimum Order Quantity:	10pcs
Price:	Negotiation
Packaging Details:	REEL
Delivery Time:	1 Day
Payment Terms:	T/T, Western Union,PayPal
Supply Ability:	18000PCS

Contact Now

Detailed Product Description

Temperature Range:	–40°C To +100°C	Payment Term:	T/T, Paypal, Western Union
Voltage:	7.0V	Current:	2.0 To 25mA
Package:	SOP-8	Factory Package:	REEL
Highlight:	chip in electronics , integrated components

Series PVT322

Microelectronic Power IC HEXFET® Power MOSFET Photovoltaic Relay Dual Pole, Normally Open 0-250V, 170mA AC/DC

General Description

The PVT322 Series Photovoltaic Relay is a dualpole, normally open solid-state relay that can replace electromechanical relays in many applications.

It utilizes International Rectifier’s HEXFET power MOSFET as the output switch, driven by an integrated circuit photovoltaic generator of novel construction.

The output switch is controlled by radiation from a GaAlAs light emitting diode (LED) which is optically isolated from the photovoltaic generator.

Series PVT322 Relays are packaged in an 8-pin, molded DIP package with either through-hole or surface mount (gull-wing) terminals.

It is available in standard plastic shipping tubes or on tape-andreel. Please refer to Part Identification information opposite.

Feature

HEXFET Power MOSFET output

Bounce-free operation

4,000 VRMS I/O isolation

Linear AC/DC operation

Solid-State Reliability

UL recognized and BABT certified

Applications

On/Off Hook switch Tip and Ring Line switching

General switching Pa

ABSOLUTE MAXIMUM RATINGS(1)

Minimum Control Current (See figure1) 2.0 mA

Maximum Control Current for Off-State Resistance @TA=+25°C 0.4 mA

Control Current Range (Caution: current limit input LED, see figure 5) 2.0 to 25 mA

Maximum Reverse Voltage 7.0 V

Minimum Dielectric Strength, Input-Output 4000 VRMS

Minimum Dielectric Strength, Pole-to-Pole 1000 VDC

Minimum Insulation Resistance, Input-Output, @TA=+25°C, 50%RH, 100VDC 1012 Ω

Maximum Capacitance, Input-Output 1.0 pF Maximum Pin

Soldering Temperature (10 seconds maximum) +260

Ambient Temperature Range: Operating -40 to +85 °C Storage -40 to +100
