PIC16LF877A-I/PT Integrated Circuit Chip Enhanced Flash Microcontrollers



PIC16F87XA

28/40/44-Pin Enhanced Flash Microcontrollers



Devices Included in this Data Sheet:

• PIC16F873A            • PIC16F874A

• PIC16F876A            • PIC16F877A



High-Performance RISC CPU:

• Only 35 single-word instructions to learn

• All single-cycle instructions except for program branches, which are two-cycle

• Operating speed: DC – 20 MHz clock input

                               DC – 200 ns instruction cycle

• Up to 8K x 14 words of Flash Program Memory,

  Up to 368 x 8 bytes of Data Memory (RAM),

  Up to 256 x 8 bytes of EEPROM Data Memory

• Pinout compatible to other 28-pin or 40/44-pin PIC16CXXX and PIC16FXXX microcontrollers



Peripheral Features:

• Timer0: 8-bit timer/counter with 8-bit prescaler

• Timer1: 16-bit timer/counter with prescaler, can be incremented during Sleep via external crystal/clock

• Timer2: 8-bit timer/counter with 8-bit period register, prescaler and postscaler

• Two Capture, Compare, PWM modules

  - Capture is 16-bit, max. resolution is 12.5 ns

  - Compare is 16-bit, max. resolution is 200 ns

  - PWM max. resolution is 10-bit

• Synchronous Serial Port (SSP) with SPI™ (Master mode) and I2C™ (Master/Slave)

• Universal Synchronous Asynchronous Receiver Transmitter (USART/SCI) with 9-bit address detection

• Parallel Slave Port (PSP)

  – 8 bits wide with external RD, WR and CS controls (40/44-pin only)

• Brown-out detection circuitry for Brown-out Reset (BOR)



Analog Features:

• 10-bit, up to 8-channel Analog-to-Digital Converter (A/D)

• Brown-out Reset (BOR)

• Analog Comparator module with:

  - Two analog comparators

  - Programmable on-chip voltage reference (VREF) module

  - Programmable input multiplexing from device inputs and internal voltage reference

  - Comparator outputs are externally accessible



Special Microcontroller Features:

• 100,000 erase/write cycle Enhanced Flash program memory typical

• 1,000,000 erase/write cycle Data EEPROM memory typical

• Data EEPROM Retention > 40 years

• Self-reprogrammable under software control

• In-Circuit Serial Programming™ (ICSP™) via two pins

• Single-supply 5V In-Circuit Serial Programming

• Watchdog Timer (WDT) with its own on-chip RC oscillator for reliable operation

• Programmable code protection

• Power saving Sleep mode

• Selectable oscillator options

• In-Circuit Debug (ICD) via two pins



CMOS Technology:

• Low-power, high-speed Flash/EEPROM technology

• Fully static design

• Wide operating voltage range (2.0V to 5.5V)

• Commercial and Industrial temperature ranges

• Low-power consumption



Absolute Maximum Ratings †

Ambient temperature under bias...........................................................................-55 to +125°C

Storage temperature ....................................................................................... -65°C to +150°C

Voltage on any pin with respect to V_SS (except V_DD, MCLR. and RA4) ....... -0.3V to (V_DD + 0.3V)

Voltage on V_DD with respect to V_SS ....................................................................... -0.3 to +7.5V

Voltage on MCLR with respect to V_SS (Note 2) .............................................................0 to +14V

Voltage on RA4 with respect to Vss..............................................................................0 to +8.5V



Total power dissipation (Note 1) ..........................................................................................1.0W

Maximum current out of V_SS pin .......................................................................................300 mA

Maximum current into V_DD pin ..........................................................................................250 mA

Input clamp current, I_IK (V_I < 0 or V_I > V_DD)..................................................................... ± 20 mA

Output clamp current, I_OK (V_O < 0 or V_O > V_DD) ............................................................. ± 20 mA



Maximum output current sunk by any I/O pin........................................................................25 mA

Maximum output current sourced by any I/O pin ..................................................................25 mA

Maximum current sunk by PORTA, PORTB and PORTE (combined) (Note 3)....................200 mA

Maximum current sourced by PORTA, PORTB and PORTE (combined) (Note 3)...............200 mA

Maximum current sunk by PORTC and PORTD (combined) (Note 3) .................................200 mA

Maximum current sourced by PORTC and PORTD (combined) (Note 3) ............................200 mA



Note

1: Power dissipation is calculated as follows: Pdis = V_DD x {I_DD - ∑ IOH} + ∑ {(V_DD - V_OH) x I_OH} + ∑(V_Ol x I_OL)

2: Voltage spikes below V_SS at the MCLR pin, inducing currents greater than 80 mA, may cause latch-up. Thus, a series resistor of 50-100Ω should be used when applying a “low” level to the MCLR pin rather than pulling this pin directly to V_SS.

3: PORTD and PORTE are not implemented on PIC16F873A/876A devices



† NOTICE: Stresses above those listed under “Absolute Maximum Ratings” may cause permanent damage to the device. This is a stress rating only and functional operation of the device at those or any other conditions above those indicated in the operation listings of this specification is not implied. Exposure to maximum rating conditions for extended periods may affect device reliability.



Pin Diagrams
