TD62004AFG IC Electronic Components Integrated Circuit Chip Program Memory

: Large Image : TD62004AFG IC Electronic Components Integrated Circuit Chip Program Memory

Product Details:

Place of Origin:	CHINA
Brand Name:	TOS
Certification:	Original Factory Pack
Model Number:	TD62004AFG

Payment & Shipping Terms:

Minimum Order Quantity:	10pcs
Price:	Negotiation
Packaging Details:	Reel
Delivery Time:	1 Day
Payment Terms:	T/T, Western Union,PayPal
Supply Ability:	5120PCS

Contact Now

Detailed Product Description

Temperature Range:	–55°C To +150°C	Payment Term:	T/T, Paypal, Western Union
Voltage:	−0.5 To 50 V	Current:	500mA
Package:	SOP-16	Factory Package:	REEL
Highlight:	chip in electronics , integrated components

TOSHIBA Bipolar Digital Integrated Circuit Silicon Monolithic

TD62001APG,TD62001AFG,TD62002APG,TD62002AFG, TD62003APG,TD62003AFG,TD62004APG,TD62004AFG

7-channel Darlington Sink Driver

Features

z Output current (single output): 500 mA (max)

z High sustaining voltage output: 50 V (min)

z Output clamp diodes

z Inputs compatible with various types of logic

z Package type APG: DIP-16 pin (Pb free package) AFG: SOP-16 pin (Pb free package)

General Description

The TD62001APG/AFG Series are high-voltage, high-current darlington drivers comprised of seven NPN darlington pairs. All units feature integral clamp diodes for switching inductive loads. Applications include relay, hammer, lamp and display (LED) drivers. The suffix (G) appended to the part number represents a Lead (Pb)-Free product.

ABSOLUTE MAXIMUM RATINGS(1)

Output sustaining voltage VCE (SUS) −0.5 to 50 V

Output current IOUT 500 mA/ch

Input voltage VIN (Note 1) −0.5 to 30 V

Input current IIN (Note 2) 25 mA

Clamp diode reverse voltage VR 50 V

Clamp diode forward current IF 500 mA

APG 1.47 Power dissipation AFG PD 0.625 (Note 3) W

Operating temperature Topr −40 to 85 °C

Storage temperature Tstg −55 to 150 °C
