CP2102-GMR SINGLE-CHIP USB TO UART BRIDGE bridge type rectifier diode bridge rectifier diode

CP2102-GMR SINGLE-CHIP USB TO UART BRIDGE bridge type rectifier diode bridge rectifier diode

Single-Chip USB to UART Data Transfer

- Integrated USB transceiver; no external resistors required

- Integrated clock; no external crystal required

- Integrated 1024-Byte EEPROM for vendor ID, product ID,

serial number, power descriptor, release number,

and product description strings

- On-chip power-on reset circuit

- On-chip voltage regulator: 3.3 V output

- 100% pin and software compatible with CP2101

USB Function Controller

- USB Specification 2.0 compliant; full-speed (12 Mbps)

- USB suspend states supported via SUSPEND pins

Asynchronous Serial Data BUS (UART)

- All handshaking and modem interface signals

- Data formats supported:

- Data bits: 5, 6, 7, and 8

- Stop bits: 1, 1.5, and 2

- Parity: odd, even, mark, space, no parity

- Baud rates: 300 bps to 1 Mbits

- 576 Byte receive buffer; 640 byte transmit buffer

- Hardware or X-On/X-Off handshaking supported

- Event character support

- Line break transmission
