Product Details:
Payment & Shipping Terms:
|
| Temperature Range: | -50 To +150 °C | Payment Term: | T/T, Paypal, Western Union |
|---|---|---|---|
| Voltage: | 17 V | Current: | 20mA |
| Package: | SOP-8 | Factory Package: | REEL |
| Highlight: | multi emitter transistor,silicon power transistors |
||
Very Low Power . . . 110 µW Typ at 5 V
Fast Response Time ...tPLH = 2.5 µs
Typ With 5-mV Overdrive
Single Supply Operation: TLC393C . . . 3 V to 16 V
TLC393I . . . 3 V to 16 V TLC393Q . . . 4 V to 16 V
TLC393M . . . 4 V to 16 V TLC193M . . . 4 V to 16 V
On-Chip ESD Protection
Dscription
The TLC193 and TLC393 consist of dual independent micropower voltage comparators designed to operate from a single supply.
They are functionally similar to the LM393 but uses one-twentieth the power for similar response times. The open-drain MOS output stage interfaces to a variety of loads and supplies.
For a similar device with a push-pull output configuration (see the TLC3702 data sheet).
Texas Instruments LinCMOS process offers superior analog performance to standard CMOS processes.
Along with the standard CMOS advantages of low power without sacrificing speed, high input impedance, and low bias currents, the LinCMOS process offers extremely stable input offset voltages, even with differential input stresses of several volts.
This characteristic makes it possible to build reliable CMOS comparators.
| ABSOLUTE MAXIMUM RATINGS(1) |
|
Supply voltage range, VDD (see Note 1) . . . . . . . . . . . . . . . . − 0.3 V to 18 V
Differential input voltage, VID (see Note 2) . . . .. . . . . . . . . . . . . . . . . ±18 V
Input voltage range, VI . . . . . . . . . . . . . . . . . . . . . . − 0.3 V to VDD
Output voltage range, VO . . . . . . . . . . . . . . . . . − 0.3 V to 16 V
Input current, II . . . . . . . . . . . . . . . . . . . . . . . . . . . . ±5 mA
Output current, IO (each output) . . .. . . . . . . . . . . . . . .20 mA
Total supply current into VDD . . .. . . . . . . . . . . . . . .40 mA
Total current out of GND . . . . . . . . . . . . . 40 mA
Continuous total power dissipation See Dissipation Rating Table
Operating free-air temperature range: TLC393C 0 °C to 70°C
TLC393I . . . . . . . . . . . . . . . . . . . − 40°C to 85°C
TLC393Q . . . . . . . . . . . − 40°C to 125°C
TLC393M . . . . . . . . . . . . − 55°C to 125°C
TLC193M . . . . . . . . . . − 55°C to 125°C
Storage temperature range . . . . . . . . . . . . . . − 65°C to 150°C
Case temperature for 60 seconds: FK package . . . . . . . . . . .260°C
Lead temperature 1,6 mm (1/16 inch) from case for 10 seconds: D or P package 260°C
Lead temperature 1,6 mm (1/16 inch) from case for 60 seconds: JG package 300 °C
|
