Kbpc3510 Rectifier Diode Single-Phase Silicon Bridge Rectifiers

: Large Image : Kbpc3510 Rectifier Diode Single-Phase Silicon Bridge Rectifiers

Product Details:

Place of Origin:	original factory
Brand Name:	Anterwell
Certification:	new & original
Model Number:	KBPC3510

Payment & Shipping Terms:

Minimum Order Quantity:	10pcs
Price:	Negotiate
Packaging Details:	Please contact me for details
Delivery Time:	1 day
Payment Terms:	T/T, Western Union, Paypal
Supply Ability:	8500pcs

Contact Now

Detailed Product Description

Maximum Recurrent Peak Reverse Voltage:	1000 V	Maximum RMS Voltage:	700 V
Maximum DC Blocking Voltage:	1000 V	Maximum Average Forward Rectified Current At Tc=55°C:	35.0 A
Operating Temperature:	-55 To +150 °C	Storage And Operation Junction Temperature:	-55 To +150 °C
Highlight:	bridge rectifier circuit , signal schottky diode

KBPC35005 THRU KBPC3510

SINGLE PHASE SILICON BRIDGE RECTIFIER

VOLTAGE: 50 TO 1000V

CURRENT: 35.0A

FEATURE

Surge overload rating: 400 A peak

High case dielectric strength

1/4”Universal fast on terminal

and φ40ml lead-wire available

MECHANICAL DATA

Polarity: Polarity symbol marked on body

Mounting: Hole thru # 8 screw

Case: metal or plastic

MAXIMUM RATINGS AND ELECTRICAL CHARACTERISTICS

(single-phase, half -wave, 60HZ, resistive or inductive load rating at 25°C, unless otherwise stated, for capacitive load, derate current by 20%)

	SYMBOL	KBPC35 005	KBPC35 01	KBPC35 02	KBPC35 04	KBPC35 06	KBPC35 08	KBPC35 10	units
Maximum Recurrent Peak Reverse Voltage	Vrrm	50	100	200	400	600	800	1000	V
Maximum RMS Voltage	Vrms	35	70	140	280	420	560	700	V
Maximum DC blocking Voltage	Vdc	50	100	200	400	600	800	1000	V
Maximum Average Forward Rectified Current at Tc=55°C	If(av)	35.0							A
Peak Forward Surge Current 8.3ms single half sine-wave superimposed on rated load	Ifsm	400.0							A
Maximum Instantaneous Forward Voltage at forward current 17.5A DC	Vf	1.1							V
Maximum DC Reverse Current Ta =25°C at rated DC blocking voltage Ta =100°C	Ir	10.0 500.0							µA
Operating Temperature	Tj	-55 to +150							°C
Storage and Operation Junction Temperature	Tstg	-55 to +150							°C

Kbpc3510 Rectifier Diode Single-Phase Silicon Bridge Rectifiers
