TLE4226G Integrated Circuit Chip Intelligent Sixfold Low-Side Switch

: Large Image : TLE4226G Integrated Circuit Chip Intelligent Sixfold Low-Side Switch

Product Details:

Place of Origin:	original factory
Brand Name:	Anterwell
Certification:	new & original
Model Number:	TLE4226G

Payment & Shipping Terms:

Minimum Order Quantity:	10pcs
Price:	Negotiate
Packaging Details:	Please contact me for details
Delivery Time:	1 day
Payment Terms:	T/T, Western Union, Paypal
Supply Ability:	8000pcs

Contact Now

Detailed Product Description

Supply Voltage:	-1 To 10 V	Supply Voltage Load Circuit:	-0.7 To 25 V
Input Voltage:	-0.7 To 20 V	Junction Temperature:	-40 To +150˚C
Storage Temperature:	-55 To 125˚C	Ambient Temperature:	– 40 To 110 ˚C
Highlight:	electronics ic chip , integrated circuit components

Intelligent Sixfold Low-Side Switch

TLE 4226 G

Bipolar-IC

Features

● Quad 50 mA outputs

● Dual 500 mA outputs

● Operating range VS = 5 V ± 5 %

● Output stages with power limiting

● Open-collector outputs

● Shorted load protected within operating range

● Clamp-diodes to ground

● Status signaling

● TTL-compatible control inputs

● Overtemperature monitoring

● Temperature range – 40 to 125 ˚C

TLE 4226 G is an integrated, sixfold low-side power switch with power limiting of the 0.5 A outputs, shorted-load protection of the 50 mA switches and Z-diodes on all switches from output to ground. TLE 4226 G is particularly suitable for automotive and industrial applications.

Absolute Maximum Ratings

Tj = – 40 to 150 ˚C

Parameter	Symbol	Limit Values		Unit	Remarks
Parameter	Symbol	min.	max.	Unit	Remarks
Voltages
Supply voltage	V_S	-1	10	V
Supply voltage load circuit	V_Q1-6	-0.7	25	V
Input voltage	V_IN1-6 , V_PREFST	-0.1	20	V
Currents
Output current	I_Q1-6				limited internally
Current at reverse poling	I_Q5-6	-500		mA
Current at reverse poling	I_Q1-4	-50		mA
Clamping current	I_QZ5-6		700	mA	see diagram
Clamping current	I_QZ1-4		70	mA
Junction temperature	Tj	-40	150	˚C	Overtemperature protection shuts down the switches 5 and 6 at 165 ˚C
Storage temperature	Tstg	-55	125	˚C

Pin Configuration (top view)

TLE4226G Integrated Circuit Chip Intelligent Sixfold Low-Side Switch

Pin Definitions and Functions

TLE4226G Integrated Circuit Chip Intelligent Sixfold Low-Side Switch

Block Diagram

TLE4226G Integrated Circuit Chip Intelligent Sixfold Low-Side Switch
