H11l1m 6 Pin Dip Optoisolators Logic Output Integrated Components

H11L1M 6-PIN DIP OPTOISOLATORS LOGIC OUTPUT integrated components

FEATURES

• High data rate, 1 MHz typical (NRZ)

• Free from latch up and oscilliation throughout voltage and temperature ranges.

• Microprocessor compatible drive

• Logic compatible output sinks 16 mA at 0.4 V maximum

• Guaranteed on/off threshold hysteresis

• Wide supply voltage capability, compatible with all popular logic systems

• Underwriters Laboratory (UL) recognized—file #E90700, Volume 2

• VDE recognized – File#102497 – Add option V (e.g., H11LIVM)

APPLICATIONS

• Logic to logic isolator

• Programmable current level sensor

• Line receiver—eliminate noise and transient problems

• A.C. to TTL conversion—square wave shaping

• Digital programming of power supplies

DESCRIPTION The H11LXM series has a high speed integrated circuit detector optically coupled to a gallium-arsenide infrared emitting diode. The output incorporates a Schmitt trigger, which provides hysteresis for noise immunity and pulse shaping. The detector circuit is optimized for simplicity of operation and utilizes an open collector output for maximum application flexibility.

• Interfaces computers with peripherals
